Specifcations
- Inputs & Outputs
- Composite video input (RCA connector) NTSC
- S-Video input (mini-DIN connector) NTSC
- Stereo audio input (2 x RCA connectors)
- IEEE 1394 In/Out connector (6-pin type)
- Analogue Video Capture to Computer
- Analog NTSC input
- DV (IEEE 1394) camcorder capture 25 Mbit/s. Full
camera control support
- Compression: MPEG-2, MPEG-1, DV, MJPEG
(Userselectable. Available real-time capture formats
depend on CPU speed.)
- Video Playback from Computer
- DV (IEEE 1394) output to camcorder 25 Mbit/s.
Full camera/device control support
- Import Formats
- Video: DV, AVI, MPEG-1, MPEG-2*, DivX®*,
MPEG-4*, 3GP(MPEG-4*), WMV, Non-encrypted DVD
titles*
- Audio: WAV, MP3
- Graphic: BMP, JPG, PCT, TGA, TIF, WMF
- Export Formats
- Video CD (VCD) or S-VCD* with optional CD burner
(CD-R or CD-RW)
- DVD* with optional DVD burner (DVD-R, DVD-RW,
DVD+R or DVD+RW)
- DV, AVI, DivX® *, RealVideo® 8, Windows Media®
9, MPEG-1, MPEG-2*, MPEG-4* files
- Apple® iPod® and Sony® PSP™ compatible (MPEG-4*)
formats
- Dolby® Digital 2 channel** & 5.1 channel**
audiot.
A Closer Look
Features
- Complete analog/digital hardware & software
solution from the leader in both categories.
- Now has output for most popular mobile devices
(Apple iPod, Sony PSP).
- DivX Pro 6 encoding for optimum performance (best
resolution at the fastest rate).
- Built in DVD authoring or Instant DVD.
Minimum System Requirements
- Windows® XP (SP2 or higher)
- Intel® Pentium® or AMD® Athlon® 1.4 GHz or higher
(2.4 GHz or higher recommended)
- 512 MB RAM (1 GB recommended)
- DirectX® 9 or higher compatible graphics card with
64 MB (ATI® Radeon® or NVIDIA® GeForce™ 3 or higher
with 128 MB recommended)
- DirectX 9 or higher compatible sound card
(Creative® Audigy® or M-Audio® recommended)
- 1 GB of disk space to install software and 3+ GB
to install bonus content
- 1 USB 2.0 (Hi-speed) port
- DVD-ROM drive to install software
- Optional:
- CD burner for creating Video CDs or Super Video
CDs (S-VCDs)*
- DVD burner for creating DVDs*
- Sound card with surround sound output required
for preview of surround sound mixes**
* Capture, import and export of MPEG-2, MPEG-4, DivX
files and DVD titles; burning S-VCD and DVDs requires
free product activation via Internet at the first
use.
** The import/editing of DVD titles with Dolby
Digital (AC3) audio, files with Dolby audio output in
Dolby Digital Audio format can be activated inside
Pinnacle Studio at additional
cost |
